embossed type
Non-combustible decorative wall panel
Products
Decorative Interior Wall Panel
We proudly introduce a new fire-resistant decorative panel for the interior, which incorporates volcanic ash, a renewable material, combined with steel slug, as the base material.
This non-combustible wall panel weighs a fraction of traditional materials and provides simple, field workability.
Its distinct halving lap-joint design allows the product panels to join neatly, reducing labor installation costs.
Its fresh, modern 3-dimensional design delivers a refreshing appearance to commercial, residential and public settings – enhancing the value of facilities and housing.
embossed type
Features
Certification
GRAVIO embossed type has been IAPMO-certified since November 2021
The weight is roughly 66% lighter than sheetrock and 40% lighter than standard wall tile
This allows Gravio to cover large wall areas with no additional support required. This is especially beneficial when installed in areas with a high ceiling.
Good workability and easy cutting with a hand saw
You can easily cut out even complicated fits with a hand saw.
Since it is a soft construction method, carpentry construction is possible(No plastering required)
Installation can be accomplished simply with adhesive and pin nails as per manufacture instructions.
2-Year Warranty for Gravio Embossed Type
Discover the elegance and functionality of Interior wall panels, with a 2-year warranty. Explore our collection and confidently transform your space. For detailed warranty information, please see below.
LIMITED WARRANTYCase
Elegance and Hospitality to
Public and Commercial Spaces
Design trend-conscious space
Stacked Stone(Blocco from Daiken)
<Charcoal>
WFEG9S123-72
Recommended spaces
Beauty salons, restaurants, cafes, boutiques
Exclusive Facilities
Stacked Stone(Blocco from Daiken)
<Sienna>
WFEG9S117-72 (Light brown)
Recommended spaces
Hotels (foyers, reception counters), Offices (drawing rooms)
Refined Peaceful Surroundings
Flusso
WFEG9S221-72 (Cocoa brown)
Recommended spaces
Hotels (guest rooms)
For Offices / Commercial facilities / Accommodations
Prestigious foyer that welcomes visitors elegantly
Industrial(Calse from Daiken)
<Pewter>
WFEG9S315-72 (Light gray)
Recommended spaces
Beauty salons, restaurants, cafes, boutiques
Design tranquility and comfortableness to cafes where people enjoy relaxation.
Stacked Stone(Blocco from Daiken)
<Sagewood>
WFEG9S119-72 (Cream brown)
Recommended spaces
Beauty salons, restaurants, cafes, boutiques
Please note and understand the following before choosing and constructing
- This product is not a natural stone or tile. It may develop chips and friction marks.
- General interior environments. This wall covering is for general interior environments. Do not use this product in places where water is constantly splashed or water is constantly accumulated, in the such as back panels of kitchen. It is not intended for outdoor settings.
- Use this product only on vertical surfaces. It is not intended for flooring applications.
- This product cannot be directly fixed on concrete, mortar, and ALC (AUTOCLAVED AERATED CONCRETE SLABS)
- Since the surface of this product is uneven and has no capacity to hold fasteners or fastening plates, wall-hung equipment (such as a display, handrail, counter, or display cabinet) cannot be directly installed over Gravio. Note that such wall-hung equipment fastening plates can be mounted by installing and attaching to wallboard a cutout of 5mm/1/4 inch thick piece of plywood in the area of the fastener.
Lineup
2pcs/Carton, 17.76sqft, 16.5sqm
S1
Stacked Stone(Blocco from DAIKEN)
The unevenness of each piece with a sandstone motif has a brick design that gives a feeling of aging.
WFEG9S111-72
(White)
(Ivory)
(Light gray)
WFEG9S117-72
(Light brown)
WFEG9S119-72
(Cream brown)
(Charcoal)
S2Flusso
A wood-end stacking design with slanted elongated beads with a flowing stone motif that create rhythmic shadows.
(White)
(Beige)
(Light gray)
(Dark gray)
(Cocoa brown)
(Sand gray)
S3
Industrial(Calse from DAIKEN)
A masonry design with a large bead size with Oya stone as a motif and unevenness giving a profound feeling.
(Ivory)
(Beige)
(Pale green)
WFEG9S315-72
(Light gray)
WFEG9S322-72
(Bronze)
WFEG9S326-72
(Dark brown)
F1
Basketweave(Curva from DAIKEN)
Curved pieces with the motif of woven fabric has a random design that feels soft.
WEFEG9F111-72
(White)
(Ivory)
(Beige)
(Pale pink)
WFEG9F120-72
(Frosty white)
(Navy blue)
F2Piante
Mosaic tile design with vegetation motif and the texture that emphasizes the shade of a gentle atmosphere.
(Ivory)
(Light gray)
(Pale pink)
(Off white)
(Pale orange)
(Cocoa beige)
Specifications
| Size: | 3 / 8 inch×18 inch×6-0feet, 2pcs /carton (17.76sqft), 33lbs /carton |
|---|---|
| Packing: | Cardboard case |
| Base material: | Volcanic silicates fiber-reinforced multi-layer board |
| Surface: | Deep carving style embossing and special multicolor coating finish |
| Edge Processing: | Halving lap joint in all sides |
| Various certifications: | ASTM E84-2018b & E84-2021 |
| Formaldehyde regulations: | Labeling exempted product |
